Longi Hi-MO 6 Solar Panel 585W (STACK OF 06 PCS)

Get the Longi Hi-MO 6 Solar Panel 585W at Subhan Electronics. Enjoy cutting-edge HPBC technology and high efficiency for superior solar energy performance.

DELIVERY AVAILABLE IN LAHORE ONLY.

Call For Price

Features

Model	LR5-72HTH-585M
Maximum power (Pmax/W)	585
Open-circuit voltage (Voc/V)	52.36
Short circuit current (Isc/A)	14.27
Peak power voltage (Vmp/V)	44.21
Peak power current (Imp/A)	13.24

Technical Specifications:

Cell Orientation: 144 (6×24)
Junction Box: IP68
Output Cable: 4mm2, +400, -200mm/±1400mm length customization available
Glass: Single glass, 3.2mm coated tempered glass
Frame: Anodized aluminum alloy frame
Packaging: 31pcs per pallet / 155pcs per 20’ GP / 620pcs per 40’ HC

Detail

The Hi-MO 6 Longi 585W Solar Panel features groundbreaking HPBC (Hybrid Passivated Back Contact) technology, offering superior temperature coefficients and minimal degradation. With a mono-facial cell design that includes 144 (72) half-cut cells, it achieves an impressive module efficiency of 22.50%. Its temperature coefficient of Pmax is an exceptional -0.290%/℃, ensuring reliable performance in various climates.

Design and Specifications

Engineered with precision, this solar panel boasts a silver-framed design with dimensions of 2278 x 1134 x 35 mm and a weight of 27.5 kg. It features a 1,400mm link with MC4-EVO2 connectors and a split box, ensuring robust installation and durability.
